STOVAX RIVA2 55 WOOD BURNING INSET STOVE

The Stovax Riva2 55 is the tallest of the three new 5.0kW Riva2 convector inset log burners from Stovax with an overall height of 754mm (30.2"), including the 54mm Profil frame option. It has the same width as the wide bodied Riva2 50 model which means it has the scale to provide a very impressive flame picture which will create an imposing focal point in any living space, especially if used at height in a hole-in-the-wall installation. The good news is that despite its huge presence the Stovax Riva2 55 has a very practical and user friendly convected and radiant heat output combined with the precision control that's going to make it very easy to live with in a typical-sized living space as well as be economic to operate. With the Stovax Riva2 55 you no longer need to specify a high output stove just to create a strong visual presence.

The Stovax Riva2 55 has pretty impressive environmental credentials too with some of the lowest emissions figures we've seen for any stove and well below the tight requirements of the 2022 Ecodesign regulations. For example it reduces particulate matter (PM2.5) by almost half of that permitted under Ecodesign making the Stovax Riva2 55 exceptionally clean burning. Like the rest of the Riva2 inset stove range, it has also been approved by Defra for burning seasoned wood logs in a Smoke Control Area (most UK urban areas). The state-of-the-art combustion chamber features pre-heated tertiary air jets which burn hydrocarbons in the combustion gases, further adding to the Stovax Riva2 55's cleaner burning performance. It will also easily handle logs of up to 350mm (14") long and the big glass area is kept clear with Stovax's Dualflow convergent air wash system which not only washes pre-heated air from the top of the glass as usual, but also from the bottom, to create a highly effective wash.

There are 3-sided and 4-sided frame options available in two widths for the Stovax Riva2 55; the minimalist 30mm Profil XS and and the beefy 54mm wide Profil. As the UK's biggest stove maker the Stovax construction standards are very high and the Stovax Riva2 55 features a premium quality steel exterior and full width and depth cast iron grate and log guard. There's a discreet removable door handle (also cast iron) and primary and secondary air controls. The primary ReIgnite boost control is concealed behind the ash pan door as it essentially only used for quick fire starts and to reignite the fire after reloading. The Stovax Riva2 55 features integrated direct external air supply (DEAS) capability as standard which can be supplied from either the base or the rear of the stove.

Designed and engineered in Britain the Stovax Riva2 55 is the culmination of over four decades of British stove engineering excellence and represents the very latest in sustainable heating technology and the highest environmental standards  an essential choice if you're looking for an inset stove with a big flame picture.



Key Facts

Stovax Riva2 55 Inset Fire Key Facts

Fascia dimensions with frame mm
3 sided 30mm Profil XS   H685  W584
3 sided 30mm Profil        H709  W632
4 sided 54mm Profil XS   H706  W584
4 sided 54mm Profil        H754  W632

Flame viewing area mm H435  W396

Combustible Distances mm                    Sides 150  Top 500


Brand Stovax
Model Stovax Riva2 55
Heat output nominal 5.0kW
Output range  4.3kW to 6.0kW depending on fuel load
Efficiency  77.1%
ErP Energy Rating  A
Defra Approved                                       Yes
Fuel                  Seasoned wood logs (less than 20% moisture content)
Airwash                                               Advanced Dualflow Airwash (top and bottom)
Air Controls                           Two slider controls for primary / boost and secondary air
Construction                                          High quality steel exterior, cast iron grate, log guard and handle
Flue Outlet                                                Top only
Flue Diameter                                           125mm / 5"
Grate Type                                           Flat cast Iron bed with ash pan
Guarantee                                                5 years when registered with Stovax
Maximum Log Length             350mm / 14" approx
Standard Colour                         Traditional Matt Black
Optional Finishes                                    None
Options   30mm Profil XS narrow 3-sided and 4-sided frames 54mm Profil wider 3-sided and 4-sided frames
Weight  85.9kg
Air Vent Required                                     Not usually in pre-2008 homes (Subject to Building Regs)
Direct Air Inlet (DEAS)                      Yes, 80mm dia rear or base, integrated and ready to add ducting
Overall Dimensions mm                  Main body: H660  W576  D350 exc DEAS spigot





Downloads

Stovax Riva2 55 Inset Fire User Instructions

Stovax Riva2 55 Inset Fire Installation Instructions

Stovax Riva2 55 Brochure


Video

See below the product video for the Stovax Riva2 55 Inset Fire
