Technical data | |
Energy efficiency class HWAM®Autopilot™ | A+ |
HWAM®SmartControl™ | A+ |
HWAM® Autopilot™ | Yes |
HWAM® Smartcontrol™ | Yes |
Capacity (kW) | 2-7kW |
Nominal heat output Autopilot™/SmartControl™ (kW) | 4,7 / 4.9 |
Smokeoutlet, Ø (mm) | 150 |
Chimney draught, recommended (Pa) | 12 |
Combustion chamber width (cm) | 28.4 -35,8 |
Height (cm) Stove body | 119,3 |
Width (cm) | 51,0 |
Depth (cm) | 51,0 |
Weight | |
Weight 4130 (kg) | 158 |
Combustion air system | |
Combustion air system can be mounted, back (Ø 100 mm) | Yes |
Combustion air system can be mounted, floor (Ø 100 mm) | Yes |
Distance to inflammable materials | |
Distance to inflammable materials, back (cm) | 10 |
Distance to inflammable materials, side(cm) | 42 |
Distance to inflammable materials, front(cm) | 90 |
Distance to inflammable materials, corner location (cm) | 10 |
All dimensions in connection with corner installation are only recommendations. | |
Distance to furnishing in front (cm) | 90 |
Efficiency, HWAM®Autopilot™/HWAM® SmartControl™ | |
Efficiency, gross/net (%) | 82 / 86 |
Approvals | |
EN 13240 (Europa) | Yes |
Art. 15a (Austria) | Yes |
NS 3058/3059 (Norway) | Yes |
The stove announcement (Denmark) | Yes |
LRV (Switzerland) | Yes |
RLU zugelassen (Germany) | Yes |
BImSchV Stufe 2 (Germany) | Yes |
Exempt under the Clean Air Act (UK) | Yes |
HETAS registrated (UK) | Yes |
