Fondis Ulys 900 Double Fronted

Fondis Ulys 900 Double Sided Inset, Showpiece, Double sided Stove

The Ulys 900 is a luxury, double sided, woodburning, inset stove. The doors open by sliding up and into the wall. The 14.9kW heat output makes the Fondis 900 double sided stove suited to the medium to large room but bear in mind that a great advantage of the advanced Ulys firebox design is that you can also run them efficiently at low output.

Technical
General
HEIGHT (MM) 1817
WIDTH (MM) 1134
DEPTH (MM) 770
INTERNAL DIAMETER OF FLUE OUTLET (MM) 175-250
FLUE DIAMETER (MM) 230
FUEL Wood
AIRWASH Yes
ECODESIGN READY Yes
ENERGY EFFICIENCY CLASS A
WEIGHT (KG) 340
MAX LOG LENGTH (CM) 60
Normal Rate
NOMINAL HEAT OUTPUT (kW) 14.9
EFFICIENCY (%) 74
CO EMISSIONS (% @ 13% O2) 0.16
DUST EMISSIONS (MG/M3 @ 13% O2) 62
WOOD CONSUMPTION (KG/H) 4.32
Reduced Rate
HEAT OUTPUT (kW) 4.9
WOOD CONSUMPTION (KG/H) 1.44
Dimensions

Fondis Ulys 900 DF Dimensions

Downloads

Fondis Ulys Manual (pdf)

Installation Supplement (pdf)

MVHR Manufacturers Declaration (pdf)

Ulys Fire Brick Exploded Diagram (pdf)

Ulys Frame Fitting Guide (pdf)
