HWAM 2630M WITH SIDE GLASS AND LOG STORE

HWAM 2630M WITH SIDE GLASS AND LOG STORE

The Hwam 2630M with log store is an extremely well made, contemporary styled, Defra approved wood burning stove which has also been DIBt tested to ensure that it will safely operate in low energy homes with the highest insulation standards such as passive house and AECB carbonlite homes. With its 4.5kW nominal heat output and wide heat output range that starts at just 2.0kW and goes all the way up to 6.0kW (depending on how many logs you load into it) the Hwam 2630M will also make an ideal choice for small to medium sized living spaces. This kind of heat flexibility also means that the Hwam 2630M would be the perfect companion to work with a heat pump.

The heat range and flame height are precisely managed with the Hwam 2620M's discreetly placed single slider control which is augmented by automatic control of the primary air via the Hwam AutoPilot which comes as standard. The AutoPilot is a purely mechanical device which has been used by Hwam for decades and ensures quicker lighting fires and much cleaner combustion as well as greater efficiency – even right up to the end of the burn cycle. This makes the Hwam 2630M very economical to run and consequently it has an A+ energy rating with an excellent tested efficiency of up to 80.3%.

The Hwam 2630M's clean modern lines are emphasised by the sleek all-over glass fronted door with its striking cool touch stainless steel handle. This door features Hwam's patented door-closing mechanism which ensures a safe and secure airtight seal with the minimum of effort. A log store and ash pan compartment is concealed with a plain push-to-open pressed steel door for a virtually seamless look. As you'd expect from the Danish stove maker the build quality on the Hwam 2630M is exceptional. Premium quality materials and keen attention to detail are in evidence everywhere from the thick steel bodywork with its gentle curves to the highly engineered compressed vermiculite lined fire chamber. The Hwam 2630M's compact semi circular footprint (it's virtually a full circle) and impressive glass area which comes from the large 3-Way air washed main window and matching height side windows, will ensure that you'll always get a satisfying view of the impressive flame patterns from wherever you are in the room.

Hwam also give you the option to upgrade the 2630M with their patented SmartControl (only available in build stage) where the room temperature can be remotely set and gentle reminders to refuel the stove can be sounded. With Hwam SmartControl electronics you'll never need to be concerned about how to achieve the optimum and most eco-friendly performance — the SmartControl will take care of it all. There are also two variations of this great Hwam 2630 contemporary wood burning stove with the other one (2630C) featuring the classic fine cast iron fire chamber door also with a large glass area.

To sum up the Hwam 2630M is a nicely proportioned and beautifully elegant wood burning convector stove with handy covered log store that has been designed with outstanding performance in mind and to create a stunning focal point in virtually any living space – especially when installed within a low energy home home.



Technical

HWAM 2630M WITH SIDE GLASS AND LOG STORE KEY FACTS


Brand: HWAM
Model

HWAM 2630M WITH SIDE GLASS AND LOG STORE

Nominal Heat Output:    nominal 4.5kW
Heat Output Range:   2.0kW to 6.0kW depending on fuel load
Efficiency (Net):   Up to 80.3%
ErP Energy Rating A+
Defra Smoke Exempt:   Yes
DiBt Tested Yes
Fuel:   Seasoned wood logs (less than 20% moisture content)
Airwash:   3-Way (top and both sides)
Air Controls:

Single slider plus Hwam Autopilot

Construction: Cast iron door and steel bodywork
Flue Outlet:    Top or Rear (top closure plate required for rear fitting)
Flue Diameter 150mm  / 6"
Grate Type Flat bed
Guarantee:    5 Years
Maximum Log Length 250mm / 10" approx
Standard Colour

Matt black

Optional Finishes:   Grey
Options:

Direct external air supply system

Top flue outlet blanking plate (when using rear flue)

Hwam SmartControl

Net Weight:   73.0kg
Air vent required:    Not usually in pre-2008 homes (Subject to Building Regs)
Suitable for 12mm Hearth:   Yes. NB hearth still required
Direct Air Inlet (DEAS):  100mm dia. Base or rear (additional kit required)
Overall Dimensions:  H1000  W430  D380
Minimum Combustible Distances (mm):   Sides 360  Rear 190
